| Model | kW | Rounds/hour | Circulation volume |
|---|---|---|---|
| TMR3D 040 | 4.0 | 1450/273 at 50 Hz | 2374 m³ |
| TMR3D 055 | 5.5 | 1450/273 at 50 Hz | 3046 m³ |
| TMR3D 075 | 7.5 | 1450/273 at 50 Hz | 3798 m³ |
| TMR3D 110 | 11.0 | 1450/273 at 50 Hz | 5364 m³ |
| TMR3D 170 | 17.0 | 1450/273 at 50 Hz | 6638 m³ |
| TMR3D 220 | 22.0 | 1450/273 at 50 Hz | 7622 m³ |
Products
Submersible Agitators – TMR3D
Item no.: N/ASubmersible Agitators – TMR3D are agitators with three blades for medium and thick manure fluids in fermentation, slurry and wastewater tanks.
The three blades optimise agitation and homogenization processes for thick fluids e.g., when mixing in storage tanks with liquid slurry, slurry channels or during homogenization of biomass and wastewater.
Benefits
- Three phase motor 400 V, 50 Hz, 1,450 rounds per minute, electric motor with oil filling
- Highly wear-resistant slide ring sealing as standard
- Submersion depth max. 10 m. (other depths on request)
- Secures optimal homogenization
