Mini purification systems – SO & SOP

Item no.: N/A

Our mini purification systems are designed for the treatment of wastewater in compliance with the SO and SOP purification classes.

Wastewater is first pre-treated in a precipitation tank before being gradually and time-controlled pumped into the mini purification system. Within the system, wastewater undergoes thorough treatment using naturally occurring microorganisms. After the purification process is complete, the treated water can be safely released into streams.

Our mini purification systems meet the requirements of the SO purification class, which includes enhanced reduction of organic material and effective nitrification. By incorporating phosphorous removal, the system also fulfills the SOP purification class requirements, ensuring increased reduction of organic material, nitrification, and phosphorous.

Category:

Benefits

  • Standards-compliant: Meets the requirements of SO purification class.
  • Environmentally safe discharge: Treated wastewater can be safely released into streams.

Comes with

Tunetanken mini purification systems are delivered with cover, excl. precipitation tanks.

Sizes and Specifications


Diameter

Size

Height
1050 mm 5 PE KGV 1850 mm
1050 mm 10 PE KGV 1850 mm
2000 mm 15 PE KGV 1850 mm
2000 mm 20 PE KGV 1850 mm
2000 mm 30 PE KGV 1850 mm
Phosphorus removal fluid
